Hydraulic briquette Machine
Our hydraulic briquetting machine is a state-of-the-art solution designed to convert agricultural into highdensity briquettes. This machine utilizes advanced hydraulic technology to compress a variety of waste materials, such as biomass, agricultural residues, into solid briquettes. The process is not only efficient but also eco-friendly, providing an effective way to manage waste and produce a renewable energy source.
Specifications:
| Parameter | Specification |
|---|---|
| Motor | 1440 RPM |
| Motor RPM | 1440 RPM |
| Hydraulic Pressure | 2500 PSI |
| Hydraulic Oil Capacity | 70 Liters |
| Oil Grade | 68 |
| Hydraulic Pump Flow Rate | 24 Lpm |
| Production Capacity | 1 Tone per day |
Cylinder 1
| Parameter | Specification |
|---|---|
| Cylinder Piston Stroke | 565 mm |
| Cylinder Piston Diameter | 5o mm |
| Cylinder Barrel Diameter | 100 mm |
Cylinder 2
| Parameter | Specification |
|---|---|
| Cylinder Piston Stroke | 260 mm |
| Cylinder Piston Diameter | 22 mm |
| Cylinder Barrel Diameter | 60 mm |
